PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards

PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards
PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards

Large Image :  PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards

Product Details:

Place of Origin: China
Brand Name: ChuangWei
Certification: CE
Model Number: CWVC-6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 5-7 days
Supply Ability: 50 sets per month
Detailed Product Description
Color: White Laser Power: 12/15W(optional)
Type: UV Working Size: 300*300 Mm
Size: 1000mm*940mm *1520 Mm Precision: ±20 μm
Laser Brand: USA Or Germany Laser Wavelength: 355nm
Laser Scanning Speed: 2500mm/s (max) Description: PCB Laser Cutting Equipment
High Light:

pcb laser cutting machine

,

laser pcb depaneling machine

PCB Laser Cutting Equipment for Flexible PCB Boards with 0.02mm Precision PCB Laser Cutting Equipment Parameter


Parameter











Technical parameters

Main body of laser

1000mm*940mm *1520 mm

Weight of machine

450Kg

Power

AC220 V

Laser

355 nm

Laser



Optowave 10W(US)

Material

≤1.2 mm

Precisio

±20 μm

Platfor

±2 μm

Platform

±2 μm

Working area

300*300mm

Maximum

3 KW

Vibrating

CTI(US)

Power

AC220 V

Diameter

20±5 μm

Ambient

20±2 ℃

Ambient

<60 %

The Machine

Marble


PCB Laser Cutting Equipment Advantages


  • The laser process is completely software-controlled. Varying materials or cutting contours are easily taken into account through adapting the processing parameters and laser paths.

  • In the case of laser cutting with the UV laser, no appreciable mechanical or thermal stresses occur.

  • The laser beam merely requires a few µm as a cutting channel. More components can thus be placed on a panel.

  • The system software differentiates between operation in production and setting up processes. That clearly reduces instances of faulty operation.

  • The fiducial recognition by the integrated vision system is done in the latest version around 100% faster than before.


PCB Laser Cutting Equipment Application


FPC and some relative materials;
  FPC/PCB/ Rigid-Flex PCB cutting, Camera module cutting.


PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards 0            PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards 1



PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards 2PCB Depaneling Machine 1000mm*940mm*1520mm for Flexible PCB Boards 3
