Workstation PCB Loading/unloading: | Manual | Program Edit: | Inline,offline |
---|---|---|---|
Feature: | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Poi | Positioning Accuracy: | 0.01mm |
Overall Height Offset: | 60~110mm | Spindle: | KAVO |
Cutting Precision: | 0.1mm | Manipulator Motor Type: | JiaBao Series |
Highlight: | Inline Program PCB Depaneling Machine,Program Edit PCB Depaneling Machine,0.01mm Positioning Accuracy PCB Depanelizer |
The PCB Depaneling Machine, also known as PCB Depaneling Router, PCB Router, PCB CNC Router, or PCB Milling Cutter Machine, is a highly efficient and precise cutting machine designed specifically for separating printed circuit boards (PCBs) from larger panels.
This machine is essential for the production of electronic devices, as it allows for quick and accurate separation of PCBs, reducing production time and costs.
The PCB Depaneling Machine boasts a cutting precision of 0.1mm, ensuring that each PCB is separated with utmost accuracy and minimal risk of damage. This precision is crucial for the production of high-quality electronic devices.
The machine's manipulator axis has a working area of 830mm*580mm*50mm, providing a large space for cutting and separating PCBs of different sizes and shapes. This allows for versatility in production and can accommodate various PCB designs.
The PCB Depaneling Machine features a manual loading and unloading system, which allows for easy and convenient placement and removal of PCBs. This not only saves time but also reduces the risk of damage to the PCBs during the loading and unloading process.
The maximum cutting speed of the PCB Depaneling Machine is 80mm/s, making it one of the fastest and most efficient machines in the market. This high cutting speed ensures a quick and smooth production process, increasing productivity and reducing the overall production time.
The PCB Depaneling Machine, also known as PCB CNC Router Machine, PCB Milling Cutter Machine, Printed Circuit Board Router, or PCB Separator, is an essential tool for the production of electronic devices. With its high precision, large working area, and fast cutting speed, this machine ensures efficient and accurate separation of PCBs, resulting in high-quality and cost-effective production.
Technical Parameters | Values |
---|---|
Positioning Accuracy | 0.01mm |
Cutting Precision | 0.1mm |
Function Edit | Line, Arc, Circular, U-Curve |
Workstation PCB Thickness (max) | 5mm |
Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
Name | PCB Depaneling Machine, PCB Depaneling Router, PCB Depaneling Router Machine, PCB Router, PCB CNC Router |
Manipulator Axis Working Area (max) | 830mm*580mm*50mm |
Overall Weight | 650KG |
Manipulator Positioning Repeatability | 0.001mm |
Manipulator Motor Type | JiaBao Series |
Welcome to ChuangWei, your one-stop destination for all your Printed Circuit Board (PCB) router needs. Our high-quality PCB Depaneling Machine is designed and manufactured in China, with a focus on precision, efficiency, and durability. Our product is certified with CE and comes with a minimum order quantity of just 1 set, making it accessible to all customers. With our fast delivery time of 7 days and flexible payment terms of T/T, we strive to provide the best customer experience.
Our PCB Depaneling Machine is perfect for various applications and usage scenarios. Some of them include:
Our PCB Depaneling Machine is suitable for cutting different types of PCBs, including single-sided, double-sided, and multi-layered PCBs. Its versatility makes it an essential tool for various industries.
Our PCB Depaneling Machine is characterized by the following attributes:
Our machine can handle PCBs with a thickness of up to 5mm and comes with a standard or specialized PCB fixation system. The manipulator axis has a maximum working area of 830mm*580mm*50mm, ensuring a wide range of PCB sizes can be accommodated. With a positioning accuracy of 0.01mm, our machine ensures precise and accurate cutting. The program edit function allows for inline and offline editing, providing convenience and flexibility to users.
Choose ChuangWei for all your PCB Depaneling Machine needs. Contact us today to learn more or to place an order.
ChuangWei offers customized solutions for our PCB Depaneling Router Machine, also known as Printed Circuit Board Router. Our machine is designed and manufactured in China, and is certified with CE. We have a minimum order quantity of 1 set, and our price is negotiable. Each machine is carefully packaged in a plywood case for safe transportation.
Our delivery time is 7 days and we accept T/T as our payment terms. Our supply ability is 20 sets per month, ensuring timely delivery to meet our customers' needs. Our workstation PCB fixation options include both standard and specialized options, providing flexibility for different types of PCBs.
Our PCB Depaneling Machine has a power of 2.0KW AC380V and supports both inline and offline program editing. It can handle PCB thickness ranging from 0.3mm to 3.5mm. The maximum workstation PCB size is 320*320mm.
Choose ChuangWei for customized solutions for your PCB Depaneling Router Machine needs. We are committed to providing high-quality products and excellent customer service. Contact us for more information.
Our PCB Depaneling Machine is carefully packaged in a sturdy wooden crate to ensure safe delivery. The machine is protected with foam padding and secured with straps to prevent any damage during transportation.
For international shipping, the machine will be packed in a wooden crate and then placed on a pallet for added stability. The pallet will be shrink-wrapped to keep the crate in place during transit.
We offer various shipping options to meet your specific needs. Our standard shipping method is by sea, but we also offer air freight and express delivery for faster shipping times.
Once your order is confirmed and payment is received, our team will carefully prepare your PCB Depaneling Machine for shipment. We will provide you with a tracking number so you can keep track of your package's journey.
Upon delivery, please carefully inspect the package for any signs of damage. If you notice any issues, please contact us immediately and we will work with you to resolve the problem.
Thank you for choosing our PCB Depaneling Machine. We strive to provide you with the best packaging and shipping services to ensure your machine arrives safely and on time.
