Product Details:
Payment & Shipping Terms:
|
| Cutting Precision: | 0.1mm | Overall Dimensions(W*D*H): | 1370mm*1650mm*1450mm |
|---|---|---|---|
| Overall Height Offset: | 60~110mm | PCB Thickness: | 0.3-3.5mm |
| Workstation PCB Loading/unloading: | Manual | Power: | 2.0KW AC380V |
| Workstation PCB Fixation: | Standard,specialization | Feature: | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Poi |
| High Light: | Offline Multi Blade PCB CNC Router,Multi Blade PCB CNC Router,3.5mm Thick PCB CNC Router |
||
PCB Depaneling Router Machine is a kind of special equipment for routing, depaneling and separating Printed Circuit Boards (PCBs). It is widely used in the electronic manufacturing industry. It can easily and quickly separate PCBs into single pieces, with high precision and a swift cutting speed of up to 80 mm/s. It is a perfect choice for high-volume production of PCBs.
The machine comes with a feature of routing bit life-time checking and alarm system. This alarm will remind the operator to change the routing bits when it finishes 120 m of cutting. Its routing bit first 2mm cut the first milling point, middle 2mm cut the second milling point and the last 2mm cut the third milling point to increase its life time.
It can be used to edit lines, arcs, circles and U-curves. The workstation PCB size can reach up to 320*320mm in size, and its overall weight is 650 KG. PCB Depaneling Router Machine is a reliable and efficient tool for depaneling and separating PCBs, and is definitely an ideal choice for many electronics manufacturers.
| Attribute | Techincal Parameters |
|---|---|
| Positioning Accuracy | 0.01mm |
| Cutting Precision | 0.1mm |
| Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Manipulator Motor type | JiaBao Series |
| Function edit | Line,arc,circula,U-curve |
| Cutting speed(max.) | 80mm/s |
| Workstation PCB fixation | Standard,specialization |
| Program edit | Inline,offline |
| Manipulator Positioning repeatability | 0.001mm |
| Overall Height offset | 60~110mm |
The PCB Depaneling Router Machine from ChuangWei, China is an essential tool for any electronic assembly application. It is certified by the CE and the minimum order quantity is 1 set. The price is negotiable and it is delivered in a plywood case. The delivery time is 7 days, and the payment terms are T/T. The supply ability is 20 sets per month. The manipulator axis working area is 830mm*580mm*50mm, with line, arc, circula, U-curve editing functions and a cutting precision up to 0.1mm. The workstation PCB thickness can reach up to 5mm and the size can reach up to 320*320mm.
Brand Name: ChuangWei
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
PCB Depaneling Machine, also known as PCB Depaneling Router, PCB Depaneling Router Machine, PCB Router, PCB CNC Router, is designed to cut and separate individual components from a PCB panel.
The PCB Depaneling Machine is shipped in a strong cardboard box with appropriate cushioning and void fill material to protect against shock, vibration and compression during transit. The box is properly sealed with plastic tape and labelled with shipping labels for easy identification during transit.
The box contains the PCB Depaneling Machine, a manual and instructions, a warranty certificate and other documents, all properly sealed in airtight plastic bags.
Shipping is done through trusted couriers with tracking numbers provided for customers to track their packages.
