| Function Edit: | Line,arc,circula,U-curve | Positioning Accuracy: | 0.01mm |
|---|---|---|---|
| PCB Thickness: | 0.3-3.5mm | Workstation PCB Fixation: | Standard,specialization |
| Workstation PCB Loading/unloading: | Manual | Program Edit: | Inline,offline |
| Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Manipulator Positioning Repeatability: | 0.001mm |
| High Light: | 0.3mm PCB Depaneling Machine,PCB Depaneling Machine With Manipulator Motor,U-curve PCB Depaneling Machine |
||
PCB Depaneling Machine is designed for the professional routing of printed circuit boards for industrial applications. This PCB router machine is capable of achieving a maximum workstation PCB size of 320*320mm and a manipulator positioning repeatability of 0.001mm. It is equipped with a JiaBao Series manipulator motor, providing reliable and efficient performance. For the PCB fixation, the machine offers both standard and specialization features. Additionally, it is featured with a routing bit life time checking and alarm system, which can remind the operator to change routing bits when it finishes 120M cutting. Furthermore, the routing bit is designed to cut the first milling point with the first 2mm, the second milling point with the middle 2mm, and the third milling point with the last 2mm in order to increase its life time.
| Product Name | Function Edit |
|---|---|
| PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Line,arc,circula,U-curve |
| Workstation PCB loading/unloading | Manipulator Axis Working Area(max) |
| Manual | 830mm*580mm*50mm |
| Power | Feature |
| 2.0KW AC380V | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Workstation PCB fixation | Overall Dimensions(W*D*H) |
| Standard,specialization | 1370mm*1650mm*1450mm |
| Overall Height Offset | Manipulator Motor Type |
| 60~110mm | JiaBao Series |
ChuangWei PCB Depaneling Machine is a high-precision and high-efficiency router machine, which is made in China and certified with CE. It is designed to meet the needs of the printed circuit board industry. With a minimum order quantity of 1 set, the price is negotiable. It comes with a plywood case for packaging. The delivery time is 7 days and the payment terms are T/T. The supply ability of this machine is 20 sets per month. It has a manipulator positioning repeatability of 0.001mm and an overall weight of 650KG. The overall dimension is 1370mm*1650mm*1450mm, and the manipulator axis working area is 830mm*580mm*50mm.
ChuangWei PCB Depaneling Machine is ideal for PCB depaneling, router and CNC router. It is especially suitable for the production of printed circuit board (PCB) and can realize high-speed and high-precision routing. With its unique design and precise positioning, it can be used for PCB depaneling, routing, cutting, drilling and other processing. It is a perfect choice for the production of PCB in various industries such as electronic manufacturing, medical equipment and automotive electronics.
ChuangWei PCB Depaneling Machine is the ideal choice for the production of printed circuit board. It is a reliable and efficient machine that can provide high-precision and high-speed routing, cutting, drilling and other processing. It can guarantee a high level of accuracy and repeatability, which makes it an ideal choice for various industries.
ChuangWei PCB CNC Router Machine is designed for PCB depaneling. This machine provides high accuracy and repeatable positioning repeatability, with 0.001mm. It is equipped with routing bit life time checking and alarm system to remind operator to change routing bits when it finish 120M cutting. The overall dimension is 1370mm*1650mm*1450mm and the overall height offset is 60~110mm. The packaging is plywood case and the minimum order quantity is 1 set. CE certification is available. The price is negotiable and the delivery time is 7 days. We can provide 20 sets per month and accept T/T payment term.
Packaging and Shipping of PCB Depaneling Machine
The PCB Depaneling Machine will be packaged in a well-protected box, containing bubble wrap and other protective material, to ensure the safety of the product during transport. It will be shipped with a reliable carrier, and delivery tracking will be provided to the customer.
