Product Details:
Payment & Shipping Terms:
|
| Power: | 2.0KW AC380V | Workstation PCB Thick (max): | 5mm |
|---|---|---|---|
| Overall Height Offset: | 60~110mm | Workstation PCB Size (max): | 320*320mm |
| Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Manipulator Motor Type: | JiaBao Series |
| Function Edit: | Line,arc,circula,U-curve | Manipulator Positioning Repeatability: | 0.001mm |
| High Light: | KAVO Spindle PCB CNC Router,320*320mm PCB CNC Router,3.5mm PCB CNC Router |
||
The PCB Depaneling Machine is a specialized CNC router for routing and depaneling printed circuit boards. It is equipped with a KAVO spindle that provides a highly repeatable and reliable cutting action. With its positioning accuracy of 0.01mm and positioning repeatability of 0.001mm, the machine guarantees precise and consistent results. The program editor allows for both inline and offline editing, providing great flexibility in operation.
The PCB Depaneling Machine has an overall weight of 650KG, making it a robust and reliable machine for routing and depaneling printed circuit boards. It is an ideal machine for a wide range of PCB routing and depaneling applications, such as for PCB CNC routers, printed circuit board routers, and PCB router machines.
| Parameters | Description |
|---|---|
| Overall Weight | 650KG |
| PCB Thickness | 0.3-3.5mm |
| Manipulator Positioning repeatability | 0.001mm |
| Cutting speed(max.) | 80mm/s |
| Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Name | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Overall Dimensions(W*D*H) | 1370mm*1650mm*1450mm |
| Workstation PCB loading/unloading | Manual |
| Workstation PCB size (max) | 320*320mm |
| Spindle | KAVO |
ChuangWei is a leading brand of PCB Depaneling Machine in China. With CE certification, our PCB Depaneling Machine offers the highest quality performance and reliability. This Printed Circuit Board Router, PCB Router Machine, PCB CNC Router Machine comes with a minimum order quantity of 1 set. The overall weight of the machine is 650KG. It is equipped with a manipulator motor type JiaBao Series and has a manipulator axis working area of 830mm*580mm*50mm. It can handle a PCB thickness ranging from 0.3-3.5mm and offers standard and specialization PCB fixation workstation. Additionally, the price for this PCB Depaneling Machine is negotiable and it is delivered within 7 days of payment. We are able to supply 20 sets of PCB Depaneling Machine per month and the packaging details we offer are plywood case.
PCB Depaneling Machine is delivered to customers in a well-protected and secure package. The package contains the machine and all the necessary accessories required for operation. The package is designed to protect the machine from any kind of damage during transport. It is also important to note that all the components are shipped in separate packages to avoid any kind of damage while in transit.
The package is designed to be shock-resistant and water-resistant. It is also designed to prevent any kind of physical damage. All components are packed separately in individual boxes or containers to protect them from any kind of damage. The package also includes a manual with instructions on how to use the machine.
The package is then shipped by a reliable carrier to ensure that it is delivered safely and on time. We offer a variety of shipping options to ensure that the package is delivered to the customer as soon as possible. We also provide tracking information for customers to ensure that they can keep track of their package.
