Product Details:
Payment & Shipping Terms:
|
| Cutting Speed(max.): | 80mm/s | Workstation PCB Thick (max): | 5mm |
|---|---|---|---|
| Feature: | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Poi | Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Spindle: | KAVO | Overall Dimensions(W*D*H): | 1370mm*1650mm*1450mm |
| Workstation PCB Loading/unloading: | Manual | Positioning Accuracy: | 0.01mm |
| High Light: | 5mm Thick PCB Depaneling Machine,CE PCB Depaneling Machine,PCB Depaneling Machine With Alarm System |
||
PCB Depaneling Machine is a highly specialised Printed Circuit Board Router designed for the depaneling of PCBs. It is specifically designed to quickly and accurately depanel PCBs and has a positioning accuracy of 0.01mm. This machine has overall dimensions of 1370mm*1650mm*1450mm and is equipped with a JiaBao Series motor. It is capable of handling PCBs up to 320*320mm in size and the loading and unloading of these PCBs is done manually. This machine is ideal for those who require fast and precise PCB depaneling. It is reliable, efficient and easy to use.
| Parameters | Details |
|---|---|
| Overall Dimensions(W*D*H) | 1370mm*1650mm*1450mm |
| Spindle | KAVO |
| Manipulator Axis working area(max) | 830mm*580mm*50mm |
| Positioning Accuracy | 0.01mm |
| Workstation PCB size (max) | 320*320mm |
| Manipulator Positioning repeatability | 0.001mm |
| Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Workstation PCB loading/unloading | Manual |
| Cutting speed(max.) | 80mm/s |
| PCB Thickness | 0.3-3.5mm |
| Keywords | PCB Depaneling Router Machine, PCB CNC Router Machine, PCB CNC Router Machine for PCB Depaneling |
ChuangWei PCB Depaneling Router Machine is a Printed Circuit Board Router designed to quickly and accurately separate individual boards from a panel. It is certified with CE and has a minimum order quantity of 1 Set. The price is negotiable and the packaging details are plywood case. The delivery time is 7 days and payment terms are T/T. The supply ability is 20 sets per month. It is equipped with KAVO spindle and has an overall dimension of 1370mm*1650mm*1450mm. The cutting speed is up to 80mm/s and the workstation PCB size is 320*320mm while the workstation PCB thick is up to 5mm.
ChuangWei's PCB Depaneling Machine has the characteristics of CNC Router, PCB CNC Router and PCB Depaneling Router. With its CE certification, it is available for a minimum order quantity of 1 set. With its plywood case packaging, it can be delivered within 7 days. Payment terms are T/T. Its manipulator positioning repeatability is 0.001mm with an overall dimension of 1370mm*1650mm*1450mm. It also has routing bit life time checking and alarm system. Its manipulator axis working area is 830mm*580mm*50mm, with positioning accuracy of 0.01mm.
Packaging and Shipping for PCB Depaneling Machine:
The PCB Depaneling Machine will be packed in a wood case and protected with foam. After the product is packed, it will be shipped via express courier with tracking information provided.
