Product Details:
Payment & Shipping Terms:
|
| Power: | 2.0KW AC380V | Overall Height Offset: | 60~110mm |
|---|---|---|---|
| Program Edit: | Inline,offline | Feature: | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Poi |
| Manipulator Positioning Repeatability: | 0.001mm | Workstation PCB Size (max): | 320*320mm |
| Overall Weight: | 650KG | Manipulator Motor Type: | JiaBao Series |
| High Light: | Arc PCB Depaneling Router Machine,PCB Depaneling Router Machine 2.0KW,PCB Depaneling Router Machine AC380V |
||
PCB Depaneling Machine is a specialized machine for routing printed circuit boards (PCBs). It is designed to provide a fast, accurate and repeatable process for separating PCBs from their panels. The machine features a manipulator positioning repeatability of 0.001mm, manipulator axis working area of 830mm*580mm*50mm, cutting speed of up to 80mm/s, positioning accuracy of 0.01mm, and overall dimensions of 1370mm*1650mm*1450mm. This PCB Router Machine is ideal for PCB depaneling in high-volume production lines, as it can provide high quality and reliable results. It is the perfect tool for any Printed Circuit Board Router and PCB Depaneling Router Machine.
| Product Name | Technical Parameter |
|---|---|
| Printed Circuit Board Router | Workstation PCB loading/unloading: Manual Workstation PCB thick (max): 5mm PCB Thickness: 0.3-3.5mm Overall Height offset: 60~110mm Program edit: Inline,offline Workstation PCB size (max): 320*320mm Overall Dimensions(W*D*H): 1370mm*1650mm*1450mm Function edit: Line,arc,circula,U-curve Feature: Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
PCB Depaneling Machine, made by ChuangWei, is a professional CNC Router with CE certification. It is widely used in industrial PCB production for depaneling. With a minimum order of 1 set, this machine provides an unbeatable price of negotiable. It comes with a plywood case for easy and safe transportation. The manufacturer promises to deliver the product within 7 days. Payment terms are T/T. The maximum supply capacity is 20 sets per month. The manipulator axis working area with this machine is 830mm*580mm*50mm, and the workstation PCB thick can be up to 5mm. It has a cutting precision of 0.1mm, and the program can be edited both online and offline. The overall weight of this PCB Depaneling Machine is 650KG.
Brand Name: ChuangWei
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
Program edit: Inline,offline
Workstation PCB thick (max): 5mm
Positioning Accuracy: 0.01mm
Product Name: Printed Circuit Board Router
Cutting Precision: 0.1mm
ChuangWei PCB CNC Router is a perfect choice for PCB depaneling, with inline, offline program edit, maximum workstation PCB thick up to 5mm, positioning accuracy of 0.01mm and cutting precision 0.1mm.
Certified by CE, the minimum order quantity is 1 Set and the package is plywood case. The delivery time is 7 days and the payment term is T/T. We can supply up to 20 sets per month.
Negotiable price is offered.
The PCB depaneling machine is packaged and shipped in a wooden crate that is reinforced to ensure the product is protected during transit.
The package is also equipped with foam inserts to absorb shocks and impacts that may occur during shipping.
The package also includes a detailed instruction manual that provides users with instructions on how to properly operate the PCB depaneling machine.
Prior to shipping, the package is inspected and tested to ensure that all components are in working order.
