| Prodcut Name: | Printed Circuit Board Router | Function Edit: | Line,arc,circula,U-curve |
|---|---|---|---|
| Manipulator Motor Type: | JiaBao Series | Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Positioning Accuracy: | 0.01mm | Overall Height Offset: | 60~110mm |
| Workstation PCB Size (max): | 320*320mm | Cutting Speed(max.): | 80mm/s |
| High Light: | 320*320mm PCB Depaneling Router Machine,KAVO spindle PCB Depaneling Router Machine,0.001mm PCB Depaneling Router Machine |
||
The PCB Depaneling Router Machine is a powerful and precise CNC router that features the KAVO spindle for exceptional performance. This powerful machine is capable of cutting PCBs up to 5mm thick, and features a manipulator positioning repeatability of 0.001mm. The router also has a routing bit life time checking and alarm system to remind operators to change routing bits when it finishes 120M cutting. It also features a unique routing bit system to increase its life time; the first 2mm cut the first milling point, middle 2mm cut the second milling point, and the last 2mm cut the third milling point.
| Technical Parameters | Value |
|---|---|
| Power | 2.0KW AC380V |
| Overall Weight | 650KG |
| Manipulator Positioning repeatability | 0.001mm |
| Cutting speed(max.) | 80mm/s |
| Workstation PCB thick (max) | 5mm |
| Program edit | Inline,offline |
| Workstation PCB loading/unloading | Manual |
| Manipulator Axis working area(max) | 830mm*580mm*50mm |
| Name | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Function edit | Line,arc,circula,U-curve |
ChuangWei PCB Depaneling Router Machine is a professional cutting tool designed for high precision cutting, scoring and routing of PCB boards. It is certified with CE and with a minimum order quantity of 1 set, the price is negotiable. Packaging details include plywood case for safe transportation and delivery time is within 7 days. Payment terms are T/T and the supply ability is 20 sets per month. The PCB thickness it can cut is 0.3-3.5mm, power is 2.0KW AC380V, the workstation PCB size is up to 320*320mm, overall dimensions(W*D*H) is 1370mm*1650mm*1450mm and the manipulator axis working area is 830mm*580mm*50mm. It is specifically designed to reduce the time of manual PCB depaneling process and it is the perfect solution for high precision CNC PCB depaneling routing and scoring. It is the ideal choice for various industries such as consumer electronics, automotive, aerospace, medical and so on.
Brand Name: ChuangWei
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
Cutting speed(max.): 80mm/s
Manipulator Axis working area(max): 830mm*580mm*50mm
Cutting Precision: 0.1mm
Name: PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router
Overall Weight: 650KG
Keywords: PCB CNC Router Machine, PCB CNC Router Machine, Printed Circuit Board Router Machine
Packaging and Shipping for PCB Depaneling Machine:
