Product Details:
Payment & Shipping Terms:
|
| Cutting Depth: | High Depth | Laser Wavelength: | 355nm |
|---|---|---|---|
| Advantages: | Auto Vision Positioning / Excellent Cut Finish | Operating Environment: | Friendly Environment |
| Cutting Accuracy: | High Accuracy,± 25 μm (1 Mil) | Laser Power: | 10W / 12W / 15W / 18W 30KHz |
| Laser: | Optowave | Control System: | Software Controlled |
| High Light: | Online PCB Laser Depaneling Machine,Offline PCB Laser Depaneling Machine,PCB Laser Depaneling Machine 220V |
||
Laser Depaneling Machine is a state-of-the-art PCB separator machine that provides high-quality and efficient online or offline PCB laser depaneling. This machine features Optowave laser technology and is equipped with an advanced software-controlled system, offering superior accuracy and excellent cut finish. It is specifically designed for depaneling FR4 and FPC boards with a cutting accuracy of up to ± 25 μm (1 Mil). The integrated auto vision positioning system allows for precise positioning and fast processing. With its reliable performance and high-end features, this Laser Depaneling Machine is ideal for high-volume PCB depaneling.
| Parameter | Details |
|---|---|
| Cutting Edge | Smooth Edge |
| Cutting Area | Large Area |
| Operating Environment | Friendly Environment |
| Laser | Optowave |
| Control System | Software Controlled |
| Cutting Accuracy | High Accuracy, ± 25 μm (1 Mil) |
| Function | Depaneling FR4 / FPC |
| Laser Scanning Speed | 2500mm/s Max High Speed |
| Laser Power | 10W / 12W / 15W / 18W 30KHz |
| Max. working area (X x Y x Z) | 300x300x11 Mm, 400mmX300mm(Customizable) |
Chuangwei’s laser depaneling machine is a state-of-the-art PCB depaneling equipment, designed to provide superior performance for PCB depaneling and pcb separator. It can effectively separate the PCBs into individual pieces with smooth edges and large cutting area. The features include auto vision positioning to ensure precise cutting results, excellent cut finish and high safety protection. With its laser wavelength of 355nm, it can accommodate a variety of materials with different thicknesses and sizes. With its CE certificate, Chuangwei’s laser depaneling machine is assured to provide reliable performance and meet industry safety standards.
Chuangwei’s laser depaneling machine is widely used in the fields of electronics, communications, automotive, medical and other industries. Thanks to its advantages such as easy operation, high efficiency, low cost and high accuracy, it has become the preferred choice for PCB depaneling and separator. In addition, it is provided with minimum order quantity of 1 set, and its price is negotiable. The delivery time is 10 days, and we accept payment terms such as T/T, Western Union, L/C. We can supply 260 sets each month, and each set is packed in plywood case.
Packaging and Shipping of Laser Depaneling Machine
The Laser Depaneling Machine is packaged in a cardboard box with foam inserts. The box is strong enough to protect the product during shipping. The shipping method for the Laser Depaneling Machine is via a reliable and fast delivery service such as UPS or FedEx.
