| Spindle: | KAVO | Power: | 2.0KW AC380V |
|---|---|---|---|
| Manipulator Axis Working Area(max): | 830mm*580mm*50mm | Program Edit: | Inline,offline |
| Function Edit: | Line,arc,circula,U-curve | Workstation PCB Loading/unloading: | Manual |
| Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Positioning Accuracy: | 0.01mm |
| High Light: | Walking Knife PCB Depaneling Equipment,High Cutting Precision PCB Depaneling Equipment,0.1mm Precision PCB Depaneling Equipment |
||
PCB Depaneling Machine, also known as PCB Depaneling Router or PCB Router or PCB CNC Router Machine, is an advanced CNC machine designed to quickly and accurately depanel printed circuit boards. The maximum PCB workstation size of the machine is 320*320mm, and it supports inline and offline program editing and line, arc, circle and U-curve function editing. Its overall dimensions are 1370mm*1650mm*1450mm.
This PCB CNC Router Machine is perfect for mass production of PCBs, and is capable of performing multiple operations in a single setup. It is equipped with a robust, high-speed spindle, and with a powerful software system, it can perform various PCB depaneling operations like cutting, routing, milling, drilling, beveling and more. With its high-precision, repeatable cutting capabilities, this machine ensures a great quality end product and maximum productivity.
In addition, the PCB Depaneling Machine has safety features such as a protective cover and emergency stop button, making it a safe and reliable choice for your PCB depaneling needs. With its advanced technology and easy to use interface, it is the ideal choice for PCB manufacturers who need speed and accuracy.
| Parameters | Details |
|---|---|
| Cutting Precision | 0.1mm |
| Overall Weight | 650KG |
| Workstation PCB fixation | Standard,specialization |
| Manipulator Axis working area (max) | 830mm*580mm*50mm |
| PCB Thickness | 0.3-3.5mm |
| Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Spindle | KAVO |
| Function edit | Line,arc,circula,U-curve |
| Overall Height offset | 60~110mm |
| Workstation PCB loading/unloading | Manual |
ChuangWei PCB Depaneling Machine, with CE certification, is made in China. It is a printed circuit board router with high precision. The minimum order quantity is 1 set. The price is negotiable and the packaging is plywood case. The delivery time is 7 days, and the payment terms is T/T. The supply ability is 20 sets per month. Its overall dimensions are 1370mm*1650mm*1450mm. It has a standard and specialization PCB fixation for workstation, and the positioning accuracy is 0.01mm. The manipulator motor type is JiaBao Series and the cutting precision is 0.1mm. It is ideal for a variety of applications, such as PCB depaneling router machine and printed circuit board router.
The PCB Depaneling Machine will come in a box, with the following dimensions:
Length: 10 inches
Width: 8 inches
Height: 12 inches
Weight: 15 lbs
The box will include the following components:
1. PCB Depaneling Machine
2. User Manual
3. Accessories
Shipping will be done via courier, and the transit time will depend on the destination. All necessary documentation will be provided with the shipment.
