Product Details:
Payment & Shipping Terms:
|
| Workstation PCB Loading/unloading: | Manual | Cutting Speed(max.): | 80mm/s |
|---|---|---|---|
| Program Edit: | Inline,offline | Workstation PCB Size (max): | 320*320mm |
| Function Edit: | Line,arc,circula,U-curve | Overall Weight: | 650KG |
| Workstation PCB Fixation: | Standard,specialization | Manipulator Axis Working Area(max): | 830mm*580mm*50mm |
| High Light: | AC380V PCB Depaneling Equipment,High Accuracy PCB Depaneling Equipment,3.5mm PCB Depaneling Equipment |
||
PCB Depaneling Router Machine is a cutting-edge routing machine, designed specifically for the depaneling of printed circuit boards (PCB). It features a high-precision manipulator positioning repeatability of 0.001mm, a cutting speed of up to 80mm/s, and a positioning accuracy of 0.01mm. The machine is capable of working up to 830mm*580mm*50mm, and is powered by a 2.0KW AC380V power source. This advanced PCB Router Machine is the ideal solution for depaneling needs, offering superior performance and durability. With its high-precision design, PCB Depaneling Router Machine is an ideal choice for any PCB depaneling application.
| Parameter | Detail |
|---|---|
| Cutting speed(max.) | 80mm/s |
| Power | 2.0KW AC380V |
| Manipulator Positioning repeatability | 0.001mm |
| Cutting Precision | 0.1mm |
| PCB Thickness | 0.3-3.5mm |
| Workstation PCB thick (max) | 5mm |
| Overall Dimensions(W*D*H) | 1370mm*1650mm*1450mm |
| Workstation PCB size (max) | 320*320mm |
| Spindle | KAVO |
| Product Name | PCB CNC Router Machine, PCB Depaneling Router, PCB Depaneling Router Machine |
ChuangWei PCB Depaneling Machine is a cutting-edge product made in China and certified by CE. It has a minimum order quantity of 1 Set, and is available at a negotiable price. It is packaged in a plywood case, and its delivery time is 7 days. Payment terms are T/T, and its supply ability is 20 sets per month. Its overall weight is 650KG, and its cutting speed is 80mm/s. It is capable of cutting PCBs of thickness ranging from 0.3-3.5mm, and it has a KAVO spindle. Its overall dimensions are 1370mm*1650mm*1450mm.
ChuangWei PCB Depaneling Machine is perfect for applications such as PCB CNC Router, PCB CNC Router, and PCB Depaneling Router. It is a reliable and efficient machine capable of handling any depaneling job with precise accuracy. It is easy to operate and maintain, and is suitable for all types of PCBs. With its robust design and superior performance, it is an ideal solution for any PCB depaneling job.
The PCB Depaneling Machine offered by ChuangWei is a high-performance Printed Circuit Board Router. This PCB CNC Router Machine is perfect for depaneling for PCBs with a thickness of 0.3-3.5mm. The manipulator axis working area is up to 830mm*580mm*50mm and the positioning accuracy is 0.01mm. This machine is equipped with a KAVO spindle and can cut line, arc, circle, and U-curve.
PCB Depaneling Machine is shipped in a custom-made cardboard box to ensure safe delivery to its destination. The box is made of durable materials and contains foam inserts to protect the machine from shock and vibration during shipping.
Prior to shipping, the machine is inspected to ensure that it is in working order and securely packaged. All of the accessories and components are checked to make sure they are in the right place and in good condition.
The machine is then sealed in a plastic bag and placed in the cardboard box. The box is then sealed with tape for extra security and labeled with the customer’s address. The package is then sent via a secure courier service to the customer’s doorstep.
