KAVO Spindle PCB CNC Router With Max. Cutting Speed 80mm/S 650KG Overall Weight

KAVO Spindle PCB CNC Router With Max. Cutting Speed 80mm/S 650KG Overall Weight
KAVO Spindle PCB CNC Router With Max. Cutting Speed 80mm/S 650KG Overall Weight

Large Image :  KAVO Spindle PCB CNC Router With Max. Cutting Speed 80mm/S 650KG Overall Weight

Product Details:

Place of Origin: China
Brand Name: ChuangWei
Certification: CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
Detailed Product Description
PCB Thickness: 0.3-3.5mm Manipulator Axis Working Area(max): 830mm*580mm*50mm
Cutting Precision: 0.1mm Function Edit: Line,arc,circula,U-curve
Spindle: KAVO Overall Dimensions(W*D*H): 1370mm*1650mm*1450mm
Manipulator Motor Type: JiaBao Series Workstation PCB Thick (max): 5mm
High Light:

KAVO Spindle PCB CNC Router

,

80mm/s PCB CNC Router

,

PCB CNC Router 650KG

Product Description:

PCB Depaneling Machine

The PCB Depaneling Machine is a highly efficient PCB router machine with KAVO spindle for quickly and accurately depaneling PCBs. It has an overall height offset range of 60-110mm and can reach a maximum cutting speed of 80mm/s. This PCB router machine is capable of editing lines, arcs, circles and U-curves. The PCB depaneling machine is designed with manual loading/unloading of workstations for PCBs.

This PCB router machine is ideal for complex PCB depaneling, making it a great choice for fast and accurate production needs. With its powerful KAVO spindle and intuitive functionality, it can quickly and accurately depanel PCBs while providing excellent flexibility. Whether you are looking for quick and accurate PCB depaneling or complex PCB depaneling, the PCB Depaneling Machine is the perfect choice.



Features:

  • Product Name: PCB Depaneling Machine
  • Function: Line, arc, circular, U-curve
  • Feature: Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time.
  • Power: 2.0KW AC380V
  • Manipulator Motor type: JiaBao Series
  • Cutting Precision: 0.1mm


Technical Parameters:

Parameters Value
Product Name Printed Circuit Board Router
Cutting Precision 0.1mm
Cutting Speed (Max.) 80mm/s
Manipulator Motor Type JiaBao Series
Positioning Accuracy 0.01mm
Manipulator Positioning Repeatability 0.001mm
Power 2.0KW AC380V
Overall Height Offset 60~110mm
Overall Weight 650KG
PCB Thickness 0.3-3.5mm


Applications:

ChuangWei PCB Depaneling Router Machine - CE Certified, Minimum Order Quantity 1 Set, Price Negotiable

ChuangWei is a China based company that specializes in the production of high-quality PCB depaneling router machines. The PCB depaneling router machine is certified with CE, and its minimum order quantity is one set. The price of the machine is negotiable and can be adjusted according to the customer's requirements. The machine is packaged in plywood cases to ensure that it is safely delivered to the customer. The delivery time is 7 days. Payment terms are T/T. The machine has a supply ability of 20 sets per month. The maximum manipulator axis working area is 830mm*580mm*50mm, and it has an overall weight of 650KG. The maximum workstation PCB size is 320*320mm, and the positioning accuracy is 0.01mm.



Customization:

PCB Depaneling Machine
  • Brand Name: ChuangWei
  • Place of Origin: China
  • Certification: CE
  • Minimum Order Quantity: 1 Set
  • Price: Negotiable
  • Packaging Details: plywood case
  • Delivery Time: 7 days
  • Payment Terms: T/T
  • Supply Ability: 20 sets per month
  • Overall Dimensions(W*D*H): 1370mm*1650mm*1450mm
  • Overall Weight: 650KG
  • Manipulator Axis working area(max): 830mm*580mm*50mm
  • Positioning Accuracy: 0.01mm
  • Spindle: KAVO

ChuangWei PCB Depaneling Machine is a high-quality Printed Circuit Board Router Machine and PCB CNC Router Machine. It offers an accuracy of 0.01mm with its KAVO spindle and can work with a maximum area of 830mm*580mm*50mm. It has CE certification and its overall weight is 650KG with overall dimensions of 1370mm*1650mm*1450mm. The minimum order quantity of the machine is 1 set and the delivery time is 7 days. The price is negotiable and it is packed in a plywood case. The supply ability is 20 sets per month and the payment terms are T/T.



Packing and Shipping:

Packaging and Shipping of PCB Depaneling Machine


The PCB Depaneling Machine will be securely packaged and shipped to the customer to ensure it is undamaged on arrival. The packaging will include the following:


  • The PCB Depaneling Machine itself
  • Instructions for use
  • Power cord and accessories
  • Protective packaging materials


The packaging will be designed to withstand the rigors of shipping so that the PCB Depaneling Machine arrives in perfect condition. We will work with the customer to ensure the PCB Depaneling Machine is delivered on time and to the right destination.



FAQ:

PCB Depaneling Machine
  • Q: What is the Brand Name of the PCB Depaneling Machine?

    A: The Brand Name of the PCB Depaneling Machine is ChuangWei.

  • Q: Where is the PCB Depaneling Machine made?

    A: The PCB Depaneling Machine is made in China.

  • Q: Is the PCB Depaneling Machine certified?

    A: Yes, the PCB Depaneling Machine is certified with CE.

  • Q: What is the Minimum Order Quantity?

    A: The Minimum Order Quantity is 1 Set.

  • Q: How long does it take to deliver the PCB Depaneling Machine?

    A: The PCB Depaneling Machine will be delivered in 7 days.
