| Overall Dimensions(W*D*H): | 1370mm*1650mm*1450mm | Cutting Speed(max.): | 80mm/s |
|---|---|---|---|
| Program Edit: | Inline,offline | Positioning Accuracy: | 0.01mm |
| Manipulator Axis Working Area(max): | 830mm*580mm*50mm | Function Edit: | Line,arc,circula,U-curve |
| Manipulator Positioning Repeatability: | 0.001mm | Prodcut Name: | Printed Circuit Board Router |
| High Light: | U Curve PCB Depaneling Router,PCB Depaneling Router with Manipulator,80mm/S PCB Depaneling Router |
||
PCB Depaneling Machine is a type of Printed Circuit Board (PCB) Router that is used to cut and shape PCBs. It offers cutting precision up to 0.1mm, with a KAVO spindle and JiaBao Series Manipulator Motor to ensure positioning accuracy up to 0.01mm. It is suitable for both inline and offline program editing. This PCB Router Machine is a reliable, efficient and cost-effective solution for Automatic PCB Depaneling. It also offers a variety of features, including high-speed cutting, stable operation, and precise cutting. This PCB CNC Router is also ideal for a wide range of applications, such as PCB depaneling, cutting and routing. It is also a great choice for Printed Circuit Board Router.
| Name | Parameter |
|---|---|
| Workstation PCB loading/unloading | Manual |
| Program edit | Inline,offline |
| Workstation PCB fixation | Standard,specialization |
| Overall Height offset | 60~110mm |
| PCB Thickness | 0.3-3.5mm |
| Product Name | Printed Circuit Board Router |
| Workstation PCB thick (max) | 5mm |
| Positioning Accuracy | 0.01mm |
| Name | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router |
| Cutting speed(max) | 80mm/s |
ChuangWei’s PCB Depaneling Machine is a professional Printed Circuit Board (PCB) CNC Router with high-precision positioning accuracy of 0.01mm, and cutting speed of up to 80mm/s. It is widely used for depaneling of PCBs in electronics manufacturing industries. It is designed with advanced JiaBao Series manipulator motor to ensure smooth and accurate operation. The overall dimensions of the machine are 1370mm x 1650mm x 1450mm, and the workstation can accommodate PCBs with a maximum size of 320mm x 320mm. The machine comes with CE certification, and is available at a negotiable price. Minimum order quantity is one set, and the machine is packed securely in plywood case for delivery. Delivery time is 7 days, and payment terms are T/T. The company can supply up to 20 sets of the machine per month.
ChuangWei offers a customizable PCB depaneling machine for your needs, with features including:
Our printed circuit board router, also known as a PCB depaneling router machine, is the perfect solution for efficient, fast and precise depaneling of printed circuit boards. Get your custom PCB depaneling router machine from ChuangWei today!
The packaging and shipping of the PCB Depaneling Machine is handled by a professional logistics company. The machine is thoroughly inspected for any defects before being securely wrapped in a protective material. It is then placed in a cardboard box and sealed with packing tape. The box is marked with the product name and a label listing the contents. The package is then shipped to the customer via a reliable courier service.
