Product Details:
Payment & Shipping Terms:
|
| Function Edit: | Line,arc,circula,U-curve | Overall Dimensions(W*D*H): | 1370mm*1650mm*1450mm |
|---|---|---|---|
| Workstation PCB Fixation: | Standard,specialization | Workstation PCB Size (max): | 320*320mm |
| Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Manipulator Axis Working Area(max): | 830mm*580mm*50mm |
| Manipulator Positioning Repeatability: | 0.001mm | Overall Height Offset: | 60~110mm |
| High Light: | Offline PCB CNC Router,Inline PCB CNC Router,PCB CNC Router With Manipulator Axis |
||
PCB Depaneling Machine is a professional Printed Circuit Board Router for depaneling PCBs. It is designed to provide optimal accuracy and efficiency for routing and depaneling PCBs up to 320mm x 320mm size and 5mm thick. It features inline and offline programming, and a routing bit life time checking and alarm system to remind the operator to change the routing bits when it finishes cutting 120m. The routing bit first 2mm cut the first milling point, middle 2mm cut the second milling point, and the last 2mm cut the third milling point to increase its life time. The overall height offset is adjustable from 60mm to 110mm.
PCD Depaneling Machine is the ideal choice for PCB depaneling applications, offering high precision routing and depaneling results for a wide range of applications. With its advanced features, it is the perfect solution to meet the needs of PCB manufacturers.
| Parameter | Detail |
|---|---|
| PCB Thickness | 0.3-3.5mm |
| Manipulator Axis working area (max) | 830mm*580mm*50mm |
| Name | PCB Depaneling Machine, PCB Depaneling Router, PCB Depaneling Router Machine, PCB CNC Router, PCB Router |
| Manipulator Motor type | JiaBao Series |
| Cutting speed (max.) | 80mm/s |
| Workstation PCB size (max) | 320*320mm |
| Cutting Precision | 0.1mm |
| Workstation PCB fixation | Standard, specialization |
| Workstation PCB thick (max) | 5mm |
| Manipulator Positioning repeatability | 0.001mm |
ChuangWei offers the best quality PCB Depaneling Machine with CE certification. The minimum order quantity is 1 Set. The price is negotiable and the packaging is plywood case. The delivery time is 7 days and the payment terms are T/T. The supply ability is 20 sets per month.
The PCB Depaneling Machine has a routing bit life time checking and alarm system to remind operator to change routing bits when it finish 120M cutting. The routing bit first 2mm cut the first miling point, middle 2mm cut the second milling point, the last 2mm cut the third milling point to increase its life time. The program edit is inline and offline. The positioning accuracy is 0.01mm and the overall height offset is 60~110mm. The spindle is KAVO.
Brand Name: ChuangWei
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
PCB Thickness: 0.3-3.5mm
Program edit: Inline,offline
Cutting speed(max.): 80mm/s
Manipulator Motor type: JiaBao Series
Power: 2.0KW AC380V
ChuangWei PCB Depaneling Machine is made in China and certified with CE, which is with minimum order quantity of 1 set and negotiable price. It is packed in plywood case and delivered in 7 days with T/T payment terms and supply ability of 20 sets per month. The PCB thickness is ranged from 0.3 to 3.5mm and program edit is both inline and offline. The cutting speed is up to 80mm/s and manipulator motor type is JiaBao Series with 2.0KW AC380V power.
The high quality PCB Router Machine from ChuangWei is widely used for PCB Depaneling Router Machine, PCB Router Machine for Sale and other related applications.
