80mm/S PCB Punch Die Depaneling Equipment For 0.3-3.5mm Thickness PCBs

The PCB Depaneling Machine is a highly precise CNC Router Machine designed for the production of Printed Circuit Board (PCB). This machine is equipped with a JiaBao Series manipulator motor system, allowing for a maximum PCB thickness of 5mm and a maximum PCB size of 320*320mm. The overall height offset for this machine is adjustable between 60-110mm, and its overall weight is 650KG. This machine is extremely reliable and robust, making it an ideal choice for PCB CNC Router production.

Features:

The X10 zoom-in image makes programming easier and increases the accuracy of point setting. This allows operators to have increased efficiency in their operations. It also has two sliding tables that provides simultaneous in-and-out movements to reduce tack time for better productivity.
The AUTO MARK offset system allows the CCD image to check and simulate the paths or routing to reduce unnecessary mistakes before cutting. This helps operators save time and increase accuracy. Additionally, it has a routing bit life time checking and alarm system to remind people when the bit has reached its 120M limit. This system also increases the bit life span by having the first 2mm cut the first milling point, the middle 2mm cut the second milling point, and the last 2mm cut the third milling point.
Overall, these qualities of the X10 zoom-in image make it an efficient and reliable tool for most tasks, as it helps reduce unnecessary mistakes and increase operational efficiency.


Technical Parameters:

Attribute	Value
Feature	Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time.
Overall Height offset	60~110mm
PCB Thickness	0.3-3.5mm
Cutting Precision	0.1mm
Product Name	Printed Circuit Board Router
Power	2.0KW AC380V
Manipulator Positioning repeatability	0.001mm
Cutting speed(max.)	80mm/s
Manipulator Motor type	JiaBao Series
Workstation PCB fixation	Standard, specialization



Applications:

ChuangWei's PCB Depaneling Machine is CE certified and manufactured in China. It has a minimum order quantity of 1 set and is available at a negotiable price. Packaging is provided in a plywood case and delivery is within 7 days. Payment is accepted via T/T. The machine has a supply ability of 20 sets per month. It has inline and offline program edit capabilities and a 2.0KW AC380V power supply. The overall weight of the machine is 650KG. Some of its features include a routing bit life time checking and alarm system to remind the operator when it is time to change routing bits after it has finished 120M cutting. The routing bit first 2mm cut the first milling point, middle 2mm cut the second milling point and the last 2mm cut the third milling point to increase its life time.
ChuangWei's PCB Depaneling Machine is perfect for any PCB depaneling router or PCB CNC router needs. It is suitable for a wide range of applications including electronics manufacturing, automotive, medical and aerospace industries. The user-friendly machine is quick and accurate, leaving a smooth and clean finish every time. It is also durable, with a long life span and low maintenance costs.
ChuangWei's PCB Depaneling Machine is ideal for anyone looking for an efficient, cost-effective and reliable PCB CNC router. It is a must-have for any production line or workshop. With its robust construction and intuitive design, it is sure to provide years of reliable service.
