| Positioning Accuracy: | 0.01mm | Overall Weight: | 650KG |
|---|---|---|---|
| Overall Height Offset: | 60~110mm | Power: | 2.0KW AC380V |
| Name: | PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router | Manipulator Axis Working Area(max): | 830mm*580mm*50mm |
| Cutting Precision: | 0.1mm | Workstation PCB Thick (max): | 5mm |
| High Light: | KAVO Offline PCB Depaneling Machine,AC380V Printed Circuit Board Router,80mm/s Printed Circuit Board Router |
||
PCB Depaneling Router is a CNC router machine for depaneling circuit boards. This PCB router machine is suitable for depaneling PCB boards with thickness from 0.3mm to 3.5mm. It is equipped with a routing bit life time checking and alarm system, which will remind operators to change routing bits when it finishes 120m cutting. The routing bit is designed with 3 milling points, with the first 2mm cutting the first milling point, the middle 2mm cutting the second milling point, and the last 2mm cutting the third milling point to increase its life time. It also has an overall height offset range from 60mm to 110mm, and a manipulator positioning repeatability of 0.001mm. It is powered by 2.0KW AC380V.
The X10 zoom-in image allows for easier programming and increased accuracy in setting points. This is further enhanced by two sliding tables which provide simultaneous in-and-out movement, reducing tack time for improved productivity.
AUTO MARK offset system is beneficial as it uses CCD images to check and simulate the path or routing. This is effective in avoiding unnecessary mistakes before cutting.
The routing bit life time checking and alarm system is particularly helpful in reminding operators to change the routing bits after 120M of cutting. It follows a protocol of using the first 2mm for the first milling point, the middle 2mm for the second milling point, and the last 2mm for the third milling point, extends its life time.
Finally, CCD images continue to be of great use, as they check and simulate the path or routing before the cutting process, in order to reduce any unnecessary mistakes.
| Parameter | Value |
|---|---|
| Cutting speed(max.) | 80mm/s |
| PCB Thickness | 0.3-3.5mm |
| Function edit | Line,arc,circula,U-curve |
| Overall Height offset | 60~110mm |
| Manipulator Motor type | JiaBao Series |
| Positioning Accuracy | 0.01mm |
| cutting Precision | 0.1mm |
| Workstation PCB size (max) | 320*320mm |
| Feature | Has Routing Bit Life Time Checking And Alarm System To Remind Operator To Change Routing Bits When It Finish 120M Cutting. And Routing Bit First 2mm Cut The First Miling Point, Middle 2mm Cut The Second Milling Point, The Last 2mm Cut The Third Milling Point To Increase Its Life Time. |
| Overall Weight | 650KG |
ChuangWei PCB Depaneling Machine is a quality-assured product made in China and certified by CE. With a minimum order quantity of 1 Set and a negotiable price, it comes in a plywood case and can be delivered within 7 days after payment via T/T. It is capable of providing up to 20 sets per month. It has a manual loading/unloading system and a routing bit life time checking and alarm system to remind the operator to change routing bits when it finishes 120m cutting. It also has a routing bit with a first 2mm cut as the first miling point, middle 2mm cut as the second miling point, and last 2mm cut as the third miling point, which increases its lifetime. The workstation PCB fixation is both standard and specialized, with a maximum manipulator axis working area of 830mm*580mm*50mm and an overall height offset of 60~110mm.
Brand Name: ChuangWei
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 20 sets per month
Positioning Accuracy: 0.01mm
Name: PCB Depaneling Machine,PCB Depaneling Router,PCB Depaneling Router Machine,PCB Router,PCB CNC Router
PCB Thickness: 0.3-3.5mm
Program edit: Inline,offline
Spindle: KAVO
ChuangWei PCB Depaneling Machine is a professional and efficient equipment used to separate and separate printed circuit boards. It is mainly used for the separation of the circuit board and the frame of the board, and can also be used for other materials. This machine is suitable for the production of various types of circuit boards, and the accuracy of the positioning is up to 0.01mm. Its program edit is both inline and offline, and the spindle is KAVO. The PCB thickness it can separate is from 0.3-3.5mm.
