High Volume Board PCB Router Machine PCB Depanelizer Automated Robot

High Volume Board PCB Router Machine PCB Depanelizer Automated Robot
High Volume Board PCB Router Machine PCB Depanelizer Automated Robot High Volume Board PCB Router Machine PCB Depanelizer Automated Robot High Volume Board PCB Router Machine PCB Depanelizer Automated Robot

Large Image :  High Volume Board PCB Router Machine PCB Depanelizer Automated Robot

Product Details:

Place of Origin: China
Brand Name: Chuangwei
Certification: CE
Model Number: CW-F01-S

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 5 work days
Payment Terms: Western Union, T/T, L/C, D/A
Supply Ability: 1000 set/ year
Detailed Product Description
Warranty: 1 Year Vacuum Cleaner: Yes
Routing Bit Checking: Yes Power: 220V, 4.2KW
Weight: 650kgs Name: PCB Depanelizer
High Light:

High Volume PCB Router Machine

,

PCB Depanelizer Automated Robot

,

Board PCB Router Machine



High Volume Board PCB Router Machine PCB Depanelizer Automated Robot



Manufacturer: ChuangWei

Condition: NEW.

It is a stand alone router machine specially designed to route (depanelize) printed circuit board assemblies (PCBA) into individual assemblies. The machine can accomodate larger PCBs in its two table configuration with maximum panel size of 650mm x 500mm. Its advanced control software provides user friendly "visual" programming for rapid and accurate online programming.



Included:

  • (1) Router Machine
  • (1) Power Transformer
  • (1) Vacuum cleaner
  • (1) Dust collector
  • (1) User's Guide
  • (2) Keys

Specifications:

  • Manufacturer: ChuangWei
  • Model: CW-F01-S
  • Deigned for depaneling Printed Circuit Boards and PCB panels
  • For high volume and low mix production runs
  • PCB sizes: 50x50mm to 650*500mm, 3mm thick max.
  • Stress-free breakout and safe board handling without compromising panels
  • Dust collection built-in
  • Panels enter on conveyor, Servo-driven router under board runs automatically
  • Gripping fingers remove routed boards to a pallet on an outfeed conveyor
  • Controlled by Windows PC in machine's base
  • May be programmed to carry out prehandlings and checks using tools, manipulators, and Vision system
  • Pick & Place gantry travel: X (manually adjustable), Y 725mm, Z 75mm (pneumatic), w (manually adjustable)
  • Router speed: 1500mm/s slew, 75mm/s routing
  • Automatic broken bit detection
  • SMEMA transfer protocol
  • Camera aided teaching system
  • Tool life and vacuum bag tracking



Packaging photos:

High Volume Board PCB Router Machine PCB Depanelizer Automated Robot 0  High Volume Board PCB Router Machine PCB Depanelizer Automated Robot 1
