Product Details:
Payment & Shipping Terms:
|
| Features: | Blade Set Can Be Quickly Changed. | PCB Width: | 300mm(could Be Customized) |
|---|---|---|---|
| Type: | Hay Cutter / Multi Cutter / V Cut PCB Separator | Cutting Speed: | 300-500/s |
| Blade Dimension: | Linear Blade Or Circluar Blades | Packaging Weight: | 300kgs |
| V-cut Angel: | >40° | Driven Mode: | Stepping / Servo Motor(optional) |
| High Light: | Inline V Cut PCB Depaneling Machine,V Cut PCB Depaneling Machine,Customized V-Cut PCB Separator |
||
The V-Cut PCB Separator is designed for cutting PCB boards with V-shaped groove. It offers two types of blade sets, linear blade and circular blades, each with different cutting depths. The blade set can be quickly changed to meet different cutting requirements. The air pressure of the machine can be adjusted from 0.5 to 0.8Mpa. The high-speed steel blade material ensures precise and durable cutting. It is an ideal choice for inline PCBA V-cut depaneling machine, hay cutter PCB separator and other PCB applications.
| Parameter | Specification |
|---|---|
| V-cut Angel | >40° |
| Features | Blade Set Can Be Quickly Changed. |
| Dimension | 1250(1560)mm×800mm×1295mm |
| Blade Material | High Speed Steel |
| PCB Width | 300mm(could Be Customized) |
| Air Pressure | 0.5-0.8Mpa |
| Cutting Speed | 300-500/s |
| Driven Mode | Stepping / Servo Motor(optional) |
| Type | Hay Cutter / Multi Cutter / V Cut PCB Separator |
| Packaging Weight | 300kgs |
ChuangWei brand multi-function V-Cut PCB Separator with model number CWVC-5 is an ideal tool for cutting and separating printed circuit board (PCB) with fast speed. This V-Cut PCB Separator has the CE certification and a minimum order quantity of 1Set. It comes with a wooden case packaging and will be delivered within 8-15 days after payment. The supply ability of this device is 30sets/month. The blade dimension of this V-Cut PCB Separator is either linear blade or circular blades and the cutting speed is 300-500/s with a V-cut angel more than 40°. The total weight of the packaging is 300kgs. This V-Cut PCB Separator is perfect for hay cutter, PCB separator, multi cutter and V-cut PCB separator.
Brand Name: ChuangWei
Model Number: CWVC-5
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 8-15 days after payment
Supply Ability: 30sets/month
Name: V-Cut PCB Separator
Air Pressure: 0.5-0.8Mpa
Cutting Speed: 300-500/s
Dimension: 1250(1560)mm×800mm×1295mm
PCB Width: 300mm(could Be Customized)
Our V-Cut PCB Separator is an inline V Cut PCB Separator, which is also called PCB Online V-cut Depaneling Equipment and Multi-blade PCB Depaneling Machine. It is made with premium quality materials and strictly tested for quality assurance. It is CE certified for safety and quality assurance. It is also highly customizable according to your needs. With its excellent air pressure and cutting speed, this V-Cut PCB Separator is a great choice for PCB depaneling.
V-Cut PCB Separators are packaged and shipped in padded cartons or custom-made wooden crates. The packages are designed to protect the products from any damage that may occur during transportation.
The separator is also wrapped in a protective covering to prevent it from being scratched. Additionally, extra padding is added around the separator to prevent any movement of the product while in transit.
The packages are clearly labeled with the product name and other information to ensure that the product is delivered safely and on time.
