Product Details:
Payment & Shipping Terms:
|
| Power: | 220V, 4.2KW | Panel Location: | Located By Tooling Holes Or Edges Of PCB |
|---|---|---|---|
| Working Table: | 2 | Vision System: | High Resolution CCD Video Camera |
| Panel Thickness: | 0.5-3.5mm | Standard Working Area: | 320*320mm,450*350mm,etc. |
| Routing Bit: | 0.8/1.2/1.5/1.8/2.0mm | Warranty: | One Year |
| High Light: | Manipulator PCB Depaneling machine,CCD Camera PCB Depaneling machine |
||
PCB Router Machine is a professional online or offline PCB Router depaneling machine for PCB depaneling and cutting. It is equipped with a dual workstation with nest fixture or pin fixture for board positioning, and can support FR1, FR4, MCPCB and other kinds of PCB materials. With high precision of ± 0.01mm, the machine has a standard working area of 320*320mm, 450*350mm and other sizes. Moreover, it comes with a one-year warranty. This depaneling machine is the perfect solution for PCB depaneling and cutting.
| Product Features | Specifications |
|---|---|
| Manipulator Repeatability | ±0.02mm |
| Spindle Motor | KAVO Spindle |
| Editing Function | Dry Run Vision Assisted / Test Run Mode |
| Tool Change | Manual |
| Board Positioning | Dual Workstation With Nest Fixture Or Pin Fixture |
| Name | PCB Router Machine/PCB Routing Equipment |
| Machine Dimension | 113*140*108cm |
| Resolution | ±0.01mm |
| Working Table | 2 |
| Warranty | One Year |
| System | Windows 7 System |
PCB Router Machine produced by Chuangwei is the ideal solution for precision routing of PCBs. This machine is designed to enable fast and accurate routing of PCBs in a production environment. It is perfect for depaneling and routing of PCBs, especially those with multiple boards and intricate designs. The PCB Router Machine is equipped with dual workstations with nest fixtures or pin fixtures for precise board positioning, and manual loading/unloading for maximum efficiency. It is capable of processing a standard working area of 320*320mm, 450*350mm, etc., and is able to route a wide range of PCB materials, including FR1, FR4, and MCPCB. This machine is certified by CE ISO and requires a minimum purchase order of one set. It has a weight of 500kgs and packaging is provided in plywood cases. The price is negotiable and delivery time is 7 days after payment confirmation. Payment terms are T/T, L/C, or Paypal, and the supply ability is 100 sets/month. With the PCB Router Machine from Chuangwei, you can be sure of accurate and efficient routing of PCBs with precision.
Brand Name: Chuangwei
Place of Origin: Dongguan
Certification: CE ISO
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days after payment confirm
Payment Terms: T/T, L/C,paypal
Supply Ability: 100 Sets/Month
To ensure the safe arrival of the PCB Router Machine, it is important to properly package and ship the machine. The following steps provide a guideline for packaging and shipping the PCB Router Machine.
A1: The brand of the PCB Router Machine is Chuangwei.
A2: The PCB Router Machine is produced in Dongguan.
A3: The PCB Router Machine has CE and ISO certification.
A4: The minimum order quantity of the PCB Router Machine is one set.
A5: The price of the PCB Router Machine is negotiable. The packing details is plywood case. Delivery time is 7 days after payment confirm. Payment terms is T/T, L/C,paypal. Supply ability is 100 Sets/Month.
