Product Details:
Payment & Shipping Terms:
|
| Warranty: | One Year | Panel Thickness: | 0.5-3.5mm |
|---|---|---|---|
| Panel Location: | Located By Tooling Holes Or Edges Of PCB | Machine Weight: | 500kgs |
| Dust Filtration System: | 3KW Vacuum Cleaner | Manipulator Repeatability: | ±0.02mm |
| Machine Dimension: | 113*140*108cm | Loading/Unloading: | Manual |
| High Light: | 3.5mm PCB Router Machine,Precision PCB Router Machine |
||
The Stand Alone CNC PCB Router Machine is a powerful and versatile PCB router depaneling equipment which can be used for a variety of applications. With a routing bit of 0.8/1.2/1.5/1.8/2.0mm, dual workstation with nest fixture or pin fixture, panel thickness of 0.5-3.5mm and a 3KW vacuum cleaner dust filtration system, this machine provides a highly efficient and accurate routing solution for a wide range of PCBs. It also comes with a Windows 7 system and has a machine weight of 500kgs. The PCB router depaneling equipment is designed to deliver the highest quality performance and reliability, ensuring that your production needs are met with the utmost precision.
| Parameter | Description |
|---|---|
| Spindle motor | KAVO Spindle |
| Manipulator Repeatability | ±0.02mm |
| Warranty | One Year |
| Resolution | ±0.01mm |
| Machine weight | 500kgs |
| Working Table | 2 |
| Power | 220V, 4.2KW |
| Editing Function | Dry Run Vision Assisted / Test Run Mode |
| Tool Change | Manual |
| Standard working area | 320*320mm,450*350mm,etc. |
| Application | PCB depaneling router, PCB Router Cutting Machine, PCB Depaneling Router with CCD Camera System |
Chuangwei Automatic Router Machine for PCB Depaneling
Chuangwei automatic router machine for PCB depaneling is designed for high-precision, high-efficiency and high-stability production of PCB depaneling. It is a perfect choice for the quick and accurate routing of single or double-sided boards. With the advanced vision system, the machine can be used for the accurate positioning of tooling holes or edges of PCB, and can provide high resolution CCD video camera for the real-time monitoring of routing process.
The standard working area of this machine ranges from 320*320mm to 450*350mm, and the routing bit can be 0.8/1.2/1.5/1.8/2.0mm. Besides, it also has the editing function of dry run vision assisted or test run mode. The machine is certified by CE and ISO, and the minimum order quantity is 1 set. The packaging details are plywood case, and the delivery time is 7 days after payment confirm. The payment terms are available in T/T, L/C, paypal, and the supply ability of the machine is up to 100 sets/month.
Brand Name: Chuangwei
Place of Origin: Dongguan
Certification: CE ISO
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 7 days after payment confirm
Payment Terms: T/T, L/C,paypal
Supply Ability: 100 Sets/Month
Vision system: High Resolution CCD Video Camera
Loading/Unloading: Manual
Programming: Vision Assisted Point To Point Manual Teaching
Machine dimension: 113*140*108cm
Spindle motor: KAVO Spindle
Chuangwei offers PCB Depaneling Router with CCD Camera System, used for pcba depaneling, pcba cutting, pcba routing, pcba milling and other PCB depaneling router applications.
The PCB Router Machine is packaged in a custom designed cardboard box. The box is designed to be sturdy enough to protect the product during shipping and handling.
The box contains the PCB Router Machine, a power cord, user manual, and any other necessary accessories. All items are securely packaged and cushioned to ensure that nothing is damaged during transit.
The PCB Router Machine is shipped via a reputable carrier and will usually take 2-3 business days to arrive at its destination.
