Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

Certification
Good quality PCB Depaneling for sales
Good quality PCB Depaneling for sales
The router works fine. I would like to special thanks to you one more time for your support!

—— Ahmet

I was set up your machine one week ago. İt’s good working. Thank you for all.

—— Erdem

The machine operates well, we will purchase it again

—— Jon

The machine works very well, now we train all workers.

—— Michal

I'm Online Chat Now

Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

China Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System supplier
Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System supplier Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System supplier

Large Image :  Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

Product Details:

Place of Origin: China
Brand Name: ChuangWei
Certification: CE ISO9001
Model Number: CWLS-S

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 10days
Supply Ability: 100sets
Contact Now
Detailed Product Description
Melting Time: 20-30 Minutes Tin Groove Power: 1.2KW
Small Wave Soldering Nozzle: Custom Shape Tin Tank Capacity: 15kgs/furnace
Total Power: 5KW Power: Single Phase 220V 50HZ
Size: L850*W1100*H1340mm Weight: 200KG
Name: Single Point Small Wave Soldering Nozzle White Selective Soldering Machine

Single Point Small Wave Soldering Nozzle White Selective Soldering Machine



Application: welding PCB components





Spot- and Seam Welding Laser Deposit Welding

Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

From smallest welding spots to continuous seams

Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

Repair and modification with reconditioned quality

Scanner Welding Tube and Profile Welding

Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

No time loss by movement of workpieces or processing heads

Single Point Small Wave Hot Bar Soldering Machine Laser Soldering System

Optimal laser welding of tubes and profiles





Product Parameters



Entry Name Technical Parameters
Machine model CWLS-S
Total power 5KW
Power Single Phase 220V 50HZ
Tin Tank Capacity 15kgs/furnace
Melting Time 20-30 Minutes
Tin Groove Power 1.2KW
Small Wave Soldering Nozzle Custom Shape
Size L850*W1100*H1340mm
Weight 200KG



Where conventional soldering techniques reach their limits

Laser soldering is often applied as selective laser soldering. Selective soldering processes are used in applications where other conventional selective soldering techniques reach their limits. These limits can be for example defined by temperature-sensitive components. The transfer of heat and energy through the laser beam provides the user with many advantages, especially with view to the miniaturization of sub-assemblies or sensitive components.

During the soldering process, the filler metal or alloy is heated to melting temperatures < 450°C by laser. Therefore lasers with lower output powers (typically < 100 Watts) are used to melt the wire material, soldering paste or solder deposits so that it flows in between the two closely fitted joining materials.

For soldering small parts or components within the semiconductor, electronic or opto-electronic device manufacturing or assemblies industry, the diode laser is the right choice. Diode lasers are used for selective soldering because the laser power can be precisely controlled by an analog signal and the heat input into the material is very localized. That is why laser soldering is most advantageous, compared to traditional soldering methods. The process does not damage or input heat into nearby components. That is why even very small electronic components, in the range of a few tenths of a millimeter, as well as heat sensitive electronic parts can be processed.

Fast power controllability combined with a non-contact temperature measurement to minimize thermal damage make the diode laser an ideal tool for this application.

Conventional selective soldering techniques, such as e.g. the soldering iron, need a direct mechanical contact between the soldering tool and the solder joint, or the soldering tool has to be very close to the solder joint. Yet, in many cases, this is not possible due to a lack of space. Furthermore, within conventional selective soldering processes, the energy input is either not or is very slowly able to be influenced during the soldering process.
