| Hot Bar Soldering Machine Size: | 590*640*620mm | Max.working Area: | 200*260mm |
|---|---|---|---|
| Working Air Pressure: | 0.45~0.70Mpa | Fixture: | 1 |
| Weight: | 62kg | Warranty: | Free For One Year |
| High Light: | pcb welding machine,bonding machine |
||
Automatic Hot Bar Soldering Machine Welding FPC To PCB Board
sepcification :
soldering robot
| Soldering Machine Size | 590*640*620 mm |
| Max.working area | 200*260 mm |
| Working air pressure | 0.45~0.70 Mpa |
| Fixture | 1 set |
| Soldering Machine Weight | 62 kg |
Automatic Hot Bar Soldering Machine Features :
1 . Unique pulse heat technology provides fastest soldering head heating .
2 . Programmable soldering temperature, heat-up rate and time duration for
a wide range of products . soldering robot
3 . Thermocouple is fixed in close proximity to the working surface & the
thermode , thus providing accurate temperature feedback control .
4 . Closed Loop PID temperature control with clearly visible LED display .
5 . Soldering time can be programmable and is triggered by temperature .
6 . Floating thermode ensures consistent pressure and heat transfer
between the thermode head and the parts to be joined . soldering robot
7 . Programmable pressure switch with LCD display for precise force
control .
8 . CCD camera system with magnification lens can be retrofitted for finepitch positioning .
