Automatic PCB Depaneling Separator Machine for Circuit Boards

Automatic PCB Depaneling Separator Machine for Circuit Boards
Automatic PCB Depaneling Separator Machine for Circuit Boards Automatic PCB Depaneling Separator Machine for Circuit Boards Automatic PCB Depaneling Separator Machine for Circuit Boards Automatic PCB Depaneling Separator Machine for Circuit Boards

Large Image :  Automatic PCB Depaneling Separator Machine for Circuit Boards

Product Details:

Place of Origin: China
Brand Name: Chuangwei
Certification: CE GlobalMarket
Model Number: CWV-1A460

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywooden Case will be the first consideration
Delivery Time: 3 days after payment receipt
Payment Terms: T/T
Supply Ability: 1000 Sets/Year
Detailed Product Description
Working Effect: High Color: White
Advantage: Counter Function PCB Separator: PCB Separator
Cutting Capacity: 41mm PCB Thickness: 0.6-3.5mm
Dirving: Motor Style: Blade Moving
High Light:

PCB depaneling

,

PCB Cutting Shear

Automatic PCB depaneling Separator Machine LCD Program Control



PCB cutting machine
1.Operator foolproof
2.Infrared protection
3.Calibration Blade Set
4.LCD program Control

Specification:



Model

CWV-1A460

PCB Cutting Length (mm)

410

Cutting Speed (mm/s)

100/200/300/500

Cutting Thickness (mm)

0.6~3.5

Power Supply (V)

110/220

Size (mm)

770*510*450

Weight (Kg)

55

Blade Hardness (HB)

540~567

Blade Hardness (HRC)

60~63

Blade working life for metal (Year)

0.5

Blade working life for PCB (Year)

1

Guarantee (Year)

1

Delivery (Day)

1

Min. Order (Set)

1

Ability (Set)

1000


Detailed Product Description:


1. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board),LED.

2. Mold make of SKH-11 Steel, Blade is SKH-9(From Japan), rigorous Job!!!! Dedicated

to high strength cutting, and excellent toughness, able to cut metal board  !!!!!!

Technical characteristics:


1. Structural precision, the load evenly, to eliminate internal stress

2. Safe, easy to operate

3. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board)

Feature:


1.Minimize the shearing stress to avoid micro-cracks of the solder joints.

2.Guiding device of the "V-CUT" of the PCB.

3.Ball bearing slideways for easy setting of the PCB edge guides.

4.Ball bearing slideways for easy setting of the height of the tabletop.

5.Easy operating modes: Manual by handwheel, semi-automatic by pressing the start button or fully-automatic by continuous running.

6.Cutters can be re-grinded

7.The shape of the cutter can be customer made

Our Advantage:


1. 13 Years experience on manufacturing and selling

2. Engineers available to service machinery oversea

3. One year warranty for the machines except accessories

4. Effective customer service



Automatic PCB Depaneling Separator Machine for Circuit Boards 0



Automatic PCB Depaneling Separator Machine for Circuit Boards 1
